Machinery Hire

We have a range of makes and models available to hire here at Armistead Engineering.
Available Models:

...............................................................................................

Merlo 38-14

  • Maximum lifting capacity: 3800kg
  • Maximum lifting height: 13.6m
  • Maximum forward reach: 9.1m
  • Capacity at maximum height: 2,500kg

Machine Specification

  • Weight: 9050kg
  • Length: 5590mm
  • Height: 2440mm
  • Width: 2220mm

...............................................................................................

 Merlo 40-17

  • Maximum lifting capacity: 4,000kg
  • Maximum lifting height: 16.7mm
  • Maximum forward reach: 12.5m
  • Capacity at maximum height: 2,500kg

Machine Specification

  • Weight: 10350kg
  • Length: 5790mm
  • Height: 2510mm
  • Width: 2400mm

...............................................................................................

 Merlo 60-10

  • Maximum lifting capacity: 6,000kg
  • Maximum lifting height: 9.55m
  • Maximum forward reach: 5.5m
  • Capacity at maximum height: 4,000kg

Machine Specification

  • Weight: 9840kg
  • Length: 5345mm
  • Height: 2400mm
  • Width: 2240mm

...............................................................................................

Merlo 72-10

  • Maximum lifting capacity: 6,000kg
  • Maximum lifting height: 9.55m
  • Maximum forward reach: 5.5m
  • Capacity at maximum height: 4,000kg

Machine Specification

  • Weight: 10500kg
  • Length: 5345mm
  • Height: 2400mm
  • Width: 2240mm

...............................................................................................

Merlo 40-25

  • Maximum lifting capacity: 4,000kg
  • Maximum lifting height: 25.25m
  • Maximum forward reach: 22.7m
  • Capacity at maximum height: 1,500kg

Machine Specification

  • Weight: 15450kg
  • Length: 6980mm
  • Height: 2990mm
  • Width: 2400mm

...............................................................................................

Merlo 38-13

  • Maximum lifting capacity: 3,800kg
  • Maximum lifting height: 13m
  • Maximum forward reach: 8.5m
  • Capacity at maximum height: 2,000kg

Machine Specification

  • Weight: 8700kg
  • Length: 5240mm
  • Height: 2440mm
  • Width: 2420mm

...............................................................................................

JLG 1930ES - Electric Scissor Lift

  • Platform capacity: 230kg - 2 Man + Tools
  • Platform Height Elevated: 5.72m
  • Platform Height Lowered: 0.86m

Machine Specification

  • Weight: 1,565kg
  • Length: 1.87m
  • Platform Railing Height: 1.10m
  • Width: 0.76m

...............................................................................................

Attachments available, including:

- Buckets
- Personnel Baskets
- Lifting Hooks
- Pallet Forks


Daily, weekly, long term rates available, please contact us for more details

We are able to provide CPCS trained operators for fixed, rotating machines and NPORS slinger and signaller
